Highlights
Intel Gemini Lake N4100, Quad Core
The Intel Pentium N4100 is a quad-core SoC running at 1.1-2.4 GHz
(Single Core Burst, Multi Core Burst max 2.3 GHz) and is based on the
Gemini Lake platform. Similar to the Apollo Lake predecessor, the chip
is manufactured in a 14 nm process with FinFETs but offers slightly
improved processor cores, double the amount of L2 cache, a smaller
package, a new generation of monitor outputs (Gen 10) and a partly
integrated WiFi chip. Besides four CPU cores, the chip also includes a
DirectX 12 capable GPU as well as a DDR4/LPDDR4 memory controller
(dual-channel, up to 2400 MHz). The SoC is not replaceable as it is
directly soldered to the mainboard.
Pre-installed Windows 10
Beelink S2 MINI PC is pre-installed with licensed Windows 10 home, so
that our users are able to enjoy the advanced functions of Windows OS
directly. Moreover, the built-in Cortana in Windows 10 can turn Beelink
S2 into a work assistant as well as life-partner. With Windows 10 OS,
you can sync game display to any devices of Windows 10 OS. What an
amazing scenario! When your friends are watching football matches on TV,
you can play games on Xbox and display on another PC screen.
LPDDR4 4GB RAM, eMMC 64GB ROM
Configure 4GB memory and 64GB of storage space, with smooth and
responsive navigation and apps that launch quickly.
Dual Band WIFI
With support for 2.4Ghz and 5.8Ghz band, it can transmit higher amounts
of data, and its naturally less congested.
1000M LAN
1000M LAN can improve the net speed and the performance to a large
extent.
Specification
Brand: Beelink
Model: S2
Type: Mini PC
Hardware
OS: Windows 10 64Bit
CPU: Gemini Lake N4100 , Quad Core
GPU: 2.4Ghz Intel® UHD Graphic 600
RAM: 4GB LPDDR4
ROM: 64GB eMMC
Communication
WIFI: 2.4/5.8G WiFi, 802.11ac
Bluetooth: Bluetooth4.0
LAN: 1000M
Media
Decoder Format: H.264,H.265
Video format: 4K,4K x
2K,ASF,AVC,AVI,DAT,FLV,ISO,MP4,RM,RMVB,RV,TS,VOB,VP9,WMV
Audio format:
AAC,AC3,ACC,APE,DDP,DTS,MKA,MP3,MPEG,OGA,OGG,RM,TrueHD,WAV,WMA
Photo Format: BMP,GIF,JPEG,JPG,PNG
Support 5.1 Surround Sound Output: Yes
Interface 1* 3.5mm Audio
1* DC Power Port
1* HDMI 2.0
1* LAN
1* Reset Port
1* TF Card Slot
2* USB3.0
2* USB2.0
Other Features
Language: Multi-language
Other Functions: ISO Files
HDMI Function: HDCP
Remote Controller Battery: 2pcs x AAA batteries
Power Power Consumption.: 18W
Power Type: External Power Adapter Mode
Power Supply: Charge Adapter
Dimension&Weight Product weight: 0.3370 kg
Package weight: 0.7900 kg
Product size (L x W x H): 11.90 x 11.90 x 2.00 cm / 4.69 x 4.69 x 0.79
inches
Package size (L x W x H): 13.65 x 12.90 x 8.55 cm / 5.37 x 5.08 x 3.37
inches
Package Contents
1 x Beelink S2 Mini PC
1 x Power Adapter
1 x English User Manual
1 x Mini PC Bracket |
